Supermarket shelves need to bear the weight of goods, be touched by people, and be cleaned and wiped for a long time. The material and process directly determine the "service life" and "visual texture". We take "durability + beauty" as the core and establish strict supply chain and production standards.
Material supply chain: only select high-quality raw materials that are "suitable for supermarket scenes"
Columns and beams: use "Q235 cold-rolled steel" (yield strength ≥ 235MPa), refuse "recycled steel" (to avoid rust and breakage after use), and the steel surface is treated with "pickling and phosphating" (to remove the oxide layer and enhance the adhesion of the coating) to ensure anti-rust ability (salt spray test ≥ 48 hours without rust, suitable for humid environments such as fresh food areas).
Shelf: divided into "steel shelf" and "wooden shelf" - steel shelf adopts "cold-rolled steel plate + punching design" (punching diameter 5mm, which can reduce weight and facilitate water leakage (such as fresh food area), and the surface is "electrostatic spraying" (coating thickness 60-80μm, scratch resistance level ≥3H); wooden shelf uses "E1 grade environmentally friendly particle board" (formaldehyde emission ≤0.124mg/m³, in line with food grade contact standards), and the surface is affixed with "wear-resistant fireproof film" (can directly place bread, fruit and other foods, resistant to high temperature and oil stains).
Accessory material: small parts such as buckles and hooks are made of "high-strength nylon" or "galvanized steel" (aging-resistant, service life ≥5 years), and avoid the use of ordinary plastics (easy to brittle and break).
Specification
Brand Name
LIANQIANG
Material
Cold rolled steel
Feature
Single-sided
Type
Supermarket Rack
Capacity
150kg/layer
Layer
5 Layers
Origin
Jiangsu,China(Mainland)
Function
Showcase Products
Color
For your choice
Size
Column 3*3*1.2, iron layer 30/30, back plate is iron
Column 3*3*1.2, iron layer 35/35, back plate is iron
Column 3*3*1.2, iron layer 0.6 39/39, back plate is iron
Double columns, rear 3*6*1.2, front 3*3*1.2, layer 35 board surface
Double columns, rear 3*6*1.2, front 3*3*1.2, 40-layer board
Double columns, the back is 3*8*1.5, the front is 3*3*1.2, the board surface is 35 cm
Double columns, the back is 3*8*1.5, the front is 3*3*1.2, the board surface is 40 cm
Double columns, the back is 3*8*1.8, the front is 3*3*1.2, the board surface is 44 cm
